Engine/Copier Specifications
Configuration
Console
Scanning Element
Flatbed with Moving CCD Array Image
Sensor
Printing Process
Twin Laser Beam Scanning &
Electrophotographic Printing
Toner
Dry, Dual Component
System Memory
768 MB RAM (std./max.)
Hard Disk Drive
40 GB Standard
Document Feeder
100-Sheet ARDF (Standard)
Copy Resolution
600 x 600 dpi
Grayscale
256 levels
Exposure Adjustment Manual & Automatic (Standard)
Quantity Indicator
Up to 999
Original Type
Book/Sheet/Objects
Maximum Original Size Up to 11' x 17'
Copy Size
5.5'x 8.5' to 11' x 17'
Copy Type
Plain Paper, Transparencies, Recycled
Paper, Card Stock, Letterhead
Warm-Up Time
22 seconds
First Copy Speed
MP 4001: 4.1 seconds
MP 5001: 3.5 seconds
Continuous Copying
MP 4001: 40 copies/minute (LTR)
Speed
MP 5001: 50 copies/minute (LTR)
Recovery Time
10 seconds (from Auto Off)
Power Source
120V/60Hz/12A
Dimensions
26.4' (W) x 35.8' (H) x 26.6' (D)
Weight
213.8 lbs.
Standard Paper
550 sheets x 2 trays
Capacity
100-Sheet Bypass Tray
Optional Paper
550 sheets x 2 trays OR
Capacity
2,000 x 1; 1,200-Sheet Large Capacity
Tray (LCT)
Paper Size
5.5'x 8.5' to 11' x 17'
Paper Weight
Tray 1 & 2: 16 - 45 lb. Bond/
60 - 169 g/m
2
Bypass: 14 - 58 lb. Bond/52 - 220 g/m
2
Duplex: 16 - 45 lb. Bond/60 - 169 g/m
2
Reduction Ratios
25%, 50%, 65%, 73%, 78%, 85%,
93%
Enlargement Ratios
121%, 129%, 155%, 200%, 400%
Zoom
25% to 400% in 1% increments
Standard Features
Auto Magnification, Auto Paper Select,
Auto Tray Switch, Background
Numbering, Booklet/Magazine Copy,
Center/Border Erase, Chapters,
Combine Mode, Cover Insertion,
Date Stamp, Directional Magnification,
Document Server (3,000 File Capacity),
Double Copy, Electronic/ Rotate Sorting,
English Preset Stamps, Full-Color VGA
Touch Screen, Java VM Card Type F,
8 Job Presets, 10 Job Programs,
Negative/Positive, OHP Slip Sheet,
Page Number Stamp, Paper Designate,
Sample Copy, Series Copy, Simplified
Display, 500 User Codes, User Stamps
Printer Specifications (Standard)
Print Speed
MP 4001: 40 ppm
MP 5001: 50 ppm
CPU
RM7035C-533 MHz
Standard Interfaces
10BaseT/100BaseTX, USB 2.0
Optional Interfaces
IEEE 802.11a/b/g Wireless LAN,
Bluetooth, Gigabit Ethernet, IEEE 1284
Parallel Interface Board Type A
Memory Capacity
Shared with Copier Memory
Network Protocol
TCP/IP, IPX/SPX, AppleTalk
Network Operating
Windows Vista/2000/XP/
Systems
Server 2003/2008,
Netware 3.12, 3.2, 4.1, 4.11, 5.0, 5.1,
6.0, 6.5, UNIX; Sun Solaris, HP-UX, SCO
OpenServer, RedHat Linux, IBM AIX,
Mac OS 8.6 - 9.2x, OS X 10.1 or later,
SAP R/3, NDPS Gateway, IBM iSeries/
AS/ 400 using OS/400 Host Print
Transform, Citrix Metaframe
Utilities
Web SmartDeviceMonitor,
SmartDeviceMonitor,
Web Image Monitor
Page Description
Standard PCL 5e/6 and
Languages
Adobe PostScript3 (Optional)
Print Resolution
Up to 600 dpi
Fonts for PCL 5e/6
35 Intellifonts, 10 Truetype Fonts,
13 International Fonts
Fonts for PS3
136 PostScript Fonts
Standard Features
Sample/Locked/Hold/Stored Print
Optional Features
PDF Direct Print
Scanner Specifications (Standard)
Scanning Speed
BW: 61 ipm (@200 dpi);
FC: 33 ipm (@200 dpi)
Scanning Resolution
Up to 600 dpi
Grayscale
256 levels
Scan Area
Up to 11' x 17'
Standard Interfaces
10BaseT/100BaseTX Ethernet
Optional Interfaces
Wireless LAN (802.11a/b/g),
Gigabit Ethernet
Protocol
TCP/IP, SMTP, SMB, FTP, POP3, NCP
Memory Capacity
Shared with Copier Memory
Standard Features
Embedded Scan-to-Email, HDD, Folder,
URL
File Formats
Single-Page and Multi-Page TIFF, PDF,
High Compression PDF, Single-Page
JPEG
Fax Specifications (Option)
Circuit
PSTN, PBX
Compatibility
ITU-T G3
Resolution
200 x 200/100 dpi (Standard)
400 x 400 dpi (Optional)
Compression Method MH, MR, MMR, JBIG
Scanning Speed
0.40 seconds (LEF)
Modem Speed
33.6 Kbps with Auto Fallback
Transmission Speed
G3: 3 seconds per page
(MMR Compression)
G3: 2 seconds per page
(JBIG Compression)
Memory
4 MB standard (320 pages)
28 MB maximum (2,240 pages)
Memory Backup
1 hour
Auto Dials
2,000 (with HDD)
Group Dials
100 (max. 500 numbers per group)
ID Code Programming 4 digits
User Function Key
3 keys
Standard Features
Book Transmission, Dual Access,
Image Rotation, LAN-Fax Capability,
Internet Faxing (T.37), IP Faxing (T.38),
Fax Forwarding to E-mail/HDD/Folder
Optional Features
Simultaneous operation of up to
3 lines (G3 x 3)
Security Features (Standard)
S/MIME, IPsec Communication, Locked Print Password
Encryption, Encrypt Address Book, SSL Secure Socket Layer,
PDF Encryption
One-Bin Tray BN3040 (Option)
Paper Size
5.5' x 8.5' - 11' x 17'/A3 - A5
Paper Weight
16 to 28 lb. Bond/60 - 196 g/m
2
Paper Capacity
125 sheets
SR790 Finisher (Option)
Paper Size
5.5' x 8.5' - 11' x 17'/A5 - A3
Paper Weight
14 to 68 lb. Bond/52 to 256 g/m
2
(Proof Tray)
14 to 42 lb. Bond/52 to 163 g/m
2
(Shift Tray)
Stack Capacity
Proof Tray: 250 sheets (8.5' x 11'
or smaller)
50 sheets (8.5' x 14' or larger)
Shift Tray: 1,000 sheets (8.5' x 11'
or smaller)
500 sheets (8.5' x 14' or larger)
Staple Capacity
50 sheets (8.5' x 11')
30 sheets (8.5' x 14' or larger)
Staple Position
1 staple/2 positions;
2 staples/1 position
Dimensions
10.7' (W) x 20.5' (D) x 31.2' (H)
SR3020 Booklet Finisher (Option)
Paper Size
5.5' x 8.5' - 11' x 17'
Paper Weight
14 to 43 lb. Bond/52 to 163 g/m
2
(Proof Tray)
14 to 68 lb. Bond/52 to 256 g/m
2
(Shift Tray)
Stack Capacity
Proof Tray: 250 sheets (8.5' x 11'
or smaller)
50 sheets (8.5' x 14' or larger)
Shift Tray: 2,000 sheets (8.5' x 11') LEF
1,000 sheets (8.5' x 11' - 11' x 17') SEF
100 sheets (5.5' x 8.5')
Staple Capacity
50 sheets (8.5' x 11')
30 sheets (8.5' x 14' or larger)
Staple Position
1 staple/3 positions;
2 staples/2 positions
Saddle Stitch
30 sets (2 - 5 sheets)
15 sets (6 - 10 sheets)
10 sets (11 - 15 sheets)
Dimensions
25.8' (W) x 24.2' (D) x 37.8' (H)
SR3030 Finisher (Option)
Paper Size
5.5' x 8.5' - 11' x 17'
Paper Weight
14 to 43 lb. Bond/52 to 163 g/m
2
(Proof Tray)
14 to 68 lb. Bond/52 to 256 g/m
2
(Shift Tray)
Stack Capacity
Proof Tray: 250 sheets (8.5' x 11'
or smaller)
50 sheets (8.5' x 14' or larger)
Shift Tray: 3,000 sheets (8.5' x 11') LEF
1,500 sheets (8.5' x 11' - 11' x 17') SEF
Staple Capacity
50 sheets (8.5' x 11')
30 sheets (8.5' x 14' or larger)
Staple Position
1 staple/3 positions;
2 staples/1 position
Dimensions
25.8' (W) x 24.2' (D) x 37.8' (H)
RT3000 Large Capacity Tray (Option)
Paper Size
8.5' x 11'/A4
Paper Weight
16 to 45 lb. Bond/60 - 169 g/m
2
Paper Capacity
Ricoh Aficio Mp 2000 Pcl
1,200 sheets
Dimensions
13.7' (W) x 21.3' (D) x 11.4' (H)
PB3040 Paper Feed Unit (Option)
Paper Size
5.5' x 8.5' - 11' x 17'/A5 - A3
Paper Weight
16 to 45 lb. Bond/60 to 169 g/m
2
Paper Capacity
550 sheets x 2
Dimensions
22.8' (W) x 24.4' (D) x 10.2' (H)
PB3050 Large Capacity Tray (Option)
Paper Size
8.5' x 11'/A4
Paper Weight
16 to 45 lb. Bond/60 to 169 g/m
2
Paper Capacity
2,000 sheets
Dimensions
22.8' (W) x 24.4' (D) x 10.2' (H)
Additional Options for MP 4001/MP 5001
Bluetooth Interface Unit Type 3245, Bridge Unit Type BU3030,
DOSS Type I, FAC33 Cabinet, Fax Type 5001, File Format
Converter Type E, G3 Interface Type 5000, Gigabit Ethernet
Board Type A, Handset Type 1018, HDD Encryption Unit Type A,
IEEE 1284 Parallel Interface Board Type A, IEEE 802.11a/b/g
Interface Unit Type J, Key Counter Bracket Type H, Optional
Counter Interface Type A, PostScript3 Type 5000, Punch Kit
Type 3260 (for SR3020 & SR3030), Scanner Accessibility Option
Type 4045, 32 MB Fax Memory, Removable HDD and Additional
Removable HDD, 3L68-17 USB External Keyboard, Hardware
4 Pack Bundle of PPDM
Some accessories require additional equipment or may be prerequisite for
other options.
Ricoh Aficio
MP 4001/MP 5001
Specifications
Bringing Ricoh Value to Your Organization
Ricoh technology offers a diverse portfolio of solutions to help your organization stay
competitive and move ahead. Let Ricoh show you how to empower your business to
improve critical processes, keep information secure, ensure compliance and promote
environmental sustainability while reducing the total cost of ownership.
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other
Ricoh Mp 2000 Drivers
trademarks are the property of their respective owners. Print speed may be affected by
network, application or PC performance. Specifications and external appearances are
subject to change without notice. Products are shown with optional features.
R3148
www.ricoh-usa.com
