Ultra Low Latency Integrated Receiver Decoder.

This page describes the device driver and the device window for the Ateme Kyrion CM5000 video encoder / modulator. The driver evaluates if a modulator module (L-Band or IF) is present at slot 6 and shows the modulator specific parameters only if a modulator module is detected. The Kyrion DR5000 is a new Hardware Integrated Receiver Decoder dedicated to professional contribution over satellite and IP / ASI networks. The Kyrion DR5000 is a single channel Decoder with outstanding capabilities providing easy setup and fast signal lock while achieving great robustness.


The Kyrion© DR5000 is a single channel multi-CODEC IRD, with easy setup, fast signal lock, and the industry best input robustness. Cm5000
The Kyrion© DR5000 is a future-proof solution, with HEVC software upgrade option and support for 10-bit 4:2:2, SD, HD, UHD, MPEG2 and H264. Ateme Kyrion Cm5000 User Manual Pdf
The Kyrion© DR5000 provides the industry best baseband video quality, with high quality down scaling and de-interlacing, based on ATEME 5th generation STREAM© engine.
The Kyrion© DR5000 receives feeds via 4x RF inputs, 2x ASI inputs and 2x IP inputs, all user selectable via front panel and web based user interface.
The Kyrion© DR5000 features advanced IP output forwarding options with descrambling and services filtering for re-distribution.
When used with ATEME Kyrion© CM5000 encoder, the Kyrion© DR5000 enables ultra-low latency MPEG/DVB compliant link.
Best in class video quality
Proven interoperability
Ease of use with front panel and web GUI

Ateme Kyrion Cm5000

Immediate service with ultra-fast-boot and low latency
Software upgradeability


Features:

  • SD/HD/UHD HEVC, H264, MPEG2
  • 10-bit 4:2:2
  • Ultra low latency mode
  • Confidence Audio / Video input monitoring
  • DVB-Common Interface option
  • Service filtering with remuxed output
  • Contribution over Internet support
  • DVB-S2x Demodulation
  • UHDLOCKTMSynchronization for 4K H264 reception

Specifications:

Ateme Kyrion Cm5000 Manual Pdf

Front Panel Confidence Audio/video monitoring on Front panel with LCD Menus 17-keys keyboard for input & navigation Presets import and export from USB slot Serviceable Air Filters
Rear Panel IP interface 1 x 100/BaseT Ethernet out-of-band for management 2 x 1000/BaseT Ethernet for MPEG-2 TS / MPTS forward ASI interface 2 x DVB-ASI inputs 2 x ASI outputs with MPTS de-encryption/ Descrambling Audio interface SDI Embedded up to 16 mono channels AES-EBU output on BNC up to 8 mono channels Optional XLR 600 Ohms balanced AES/Analogue audio output Up to 8 mono channels Video output 3 x 3G-SDI (SMPTE-424M) Optional CVBS BNC Analog Video Output with 1 x CINCH Analog audio stereo pair** Synchronization Genlock, Black Burst Tri-level input Genlock, Black Burst Tri-level Loop output RF interface 1 RF demodulator with 4 selectable RF inputs Loop-through output Fast Satellite Frequency locking L-Band input, C-band, Ku-band support Frequency Range: 950-2150 MHz (L-Band) Downlink / L-Band frequency calculator RF input level: -65 dBm to -25 dBm C/N, BeR, C/N margin, Link margin monitoring Automatic or Manual DVB-S or DVB-S2 selection Adjustable search Range DVB-S (DSNG EN 300174) Constellation 8PSK, FEC 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 DVB-S (EN 300421) Constellation QPSK Symbol rate up to 45 MBaud DVB-S2 (EN 302307) Constellation QPSK, 8PSK, 16APSK, 32APSK Symbol rate range for QPSK up to 68 MBaud Symbol rate range for 8PSK up to 68 MBaud Symbol rate range for 16APSK up to 45 MBaud Symbol rate range for 32APSK up to 38 MBaud Roll-Off: 0.35, 0.25, 0.20, 0.15, 0.10, and 0.05
Video
HEVC, Main 12, Main 4:2:2 10, Main 4:2:2 12 1 , 60 Mbps max H.264 (4:2:0 8-bit, 4:2:0 10-bit, 4:2:2 8-bit, 4:2:2 10-bit)* MPEG-2 (4:2:0 8-bit & 4:2:2 8-bit)* Video decoding MPEG-2, H.264 Bitrate: 1 to 80 Mbps SD up to HD 1080p50/60 TS VBR support
Audio
MPEG-1 Layer II, AAC Dolby Digital E, DD, DD+, AC3, AC3+, PCM pass through Optional Dolby Digital / Dolby digital Decoding**
Audio decoded Up to 16 mono channels on SDI and AES
Audio Pass through Up to 16 mono channels SDI Up to 8 mono channels AES
Configuration & Management
Ultra-fast -boot Web Graphic User Interface Video and Audio Confidence monitoring on front panel and web GUI 128 Presets configurations memory slots In-band and Out-Of-Band Management SNMP (MIB v2c) with remote SNMP supervisor MIB download from web GUI Firmware Update -Over-The-Air (ETSI 102-006)
Descrambling
BISS 0/1/E/ (EBU R139) DVB-CI Common Interface Hardware option to descramble Multi services descrambling included MPTS with support of major CAS vendors: Conax, Irdeto, NDS, Viaccess **
Physical & Environmental
19” 1-RU (482 x 44 x 310 mm/19”x1.73”x 12.8”) 3.4 kg/8.5 lbs. Cooling air flow from front to back User Serviceable Air Filters Power supply 100-240 VAC, 50/60 H or 48VDC ** Typical consumption 36 W Operating temperature 0 to 55 °C / +41 ° to +131 °F Storage temperature -20 to 70 °C / +32° to +158 °F Operating humidity 5 to 90% (non-condensing)

Kyrion
